X III Series User Manual
1. Press the key labeled "LSB", the screen will display the currently value,
2. Turn the X knob to set the controller number between 0 and 127,
3. Press the X knob to confirm, the screen will display you just selected controller number,
Now you can press the other keys labeled functions to set other parameters, or long press the X knob to
exit the Setting Mode.
3.6 Selecting a Smart Scale
When th
e screen display "SEL", follow these steps:
1. Press the key labeled "SCALE", the screen will display the currently scale,
2. Turn the X knob to select a scale,
3. Press the X knob to confirm, the screen will display you just selected scale name.
3.7 Changing The CC Number
The controllers of X III can be assigned to any CC Number as you like, please refer to 6.4 MIDI CC List
for details. These controllers included: Mod touch strip, 4 knobs and 6 buttons, the range between
0 and 127.
3.7.1 Changing The Knobs’CC Number
When the screen display "SEL", follow these steps:
1. Press the key labeled "ASSIGN CC", the screen will display the CC number of the last use controller,
2. Turn the knob you want to assign, K1 for instance, the screen displays "93",
3. Turn the X knob to select a CC number, select "52" for instance,
4. Press the X knob to confirm, the screen displays "93",
5. Long press the X knob to exit the Setting Mode.
Now the CC number of K1 knob is assigned to CC52 successfully.
3.7.2 Changing The Buttons’CC Number
When the screen display "SEL", follow these steps:
1. Press the key labeled "ASSIGN CC", the screen will display the CC number of the last use controller,
2. Press the button you want to assign, B2 for instance, the screen displays "26",
3. Turn the X knob to select a CC number, select "53" for instance,
4. Press the X knob to confirm, the screen displays "53" you just selected number.
5. Long press the X knob to exit the Setting Mode.
Now the CC number of B2 button is assigned to CC53 successfully. Then you should change the button
To Next Page
