1 – Introduction & Overview Toyota/Lexus DCA-8000
Safety Reminder
For safe, ecient, and accurate charging and testing, review
the safety and operating instructions in this manual before
using the analyzer. In addition, follow all manufacturer
instructions and BCI (Battery Council International) safety
recommendations.
Safety Precautions
Always use the necessary safety precautions when working
with batteries to prevent severe injury or death. Follow
all manufacturers’ instructions and BCI (Battery Council
International) safety recommendations, which include the
following precautions:
Risk of explosive gases.
Never smoke or allow a spark or
ame in the vicinity of a battery.
Batteries can produce a highly explosive mix
of hydrogen gas and oxygen, even when the
battery is not in operation. Always work in a
well-ventilated area.
Wash hands after handling.
REQUIRED BY CALIFORNIA PROP. 65: Battery
posts, terminals, and related accessories contain
lead and lead compounds, chemicals known to
the state of California to cause cancer and birth
defects or other reproductive harm.
9 Battery acid is highly corrosive. If acid enters your eyes, im-
mediately ush them thoroughly with cold running water
for at least 15 minutes and seek medical attention. If bat-
tery acid gets on your skin or clothing, wash immediately
with a mixture of water and baking soda.
9 Always wear proper safety glasses or face shield when
working with or around batteries.
9 Keep hair, hands, and clothing as well as the analyzer
cords and cables away from moving engine parts.
9 Remove any jewelry or watches before you start servicing
the battery.
9 Use caution when working with metallic tools to prevent
sparks or short circuits.
9 Never lean over a battery when testing, charging, or boost
charging.
9 Never charge a frozen battery. Gases may form and crack
the case, causing battery acid to spray out.
Manual Conventions
This manual uses these symbols and typographical conventions:
Symbol Description
The safety symbol indicates instructions for
avoiding hazardous conditions and personal injury.
The safety symbol with the words CAUTION,
WARNING, or DANGER indicates instructions for
avoiding hazardous conditions and personal injury.
The wrench symbol indicates procedural notes and
helpful information.
Bold
Letters
The text for screen options are in Bold letters.
Front View
Thermal Printer Charger Power Button
Touch Screen Display USB Port
Rear View
Communication Cable
Connection
Circuit Breaker Reset
Charge Cable
Connections
Power Cord Socket
VIN Scanner Connection
(DB-9)
For Charger Cart
Mounting Bolts
1 – Introduction & Overview
To Next Page
