Midtronics MDX-655P User Manual

• 21 •
Printer Troubleshooting
If the tester is not connected to a 12-volt battery with at least 11.5 volts of power
or the paper sensor does not detect paper in the compartment during the print
process, the tester displays one of error messages described in the table:
Error Message Interpretation
PRINTER OUT OF PAPER
REPLACE WITH THERMAL
PRINTER PAPER.
2.5 IN. DIA. MAX
2.25 IN. WIDE MAX
√ Verify that the paper is inserted correctly.
√ Insert a new roll of paper.
√
Verify that the paper sensor is clean and undamaged
BATTERY POWER TOO
LOW TO USE PRINTER.
CONNECT TO FULLY
CHARGED BATTERY.
11.50 V TO 16.00 V
To print, the tester must be properly connected to a
vehicle battery having at least 9 volts.
√ Connect to a vehicle battery with enough voltage to
enable printing.
√ Make sure that the clamps are connected properly:
red clamp to the positive (+) terminal and the black
clamp to the negative (-) terminal.
√ Check that both sides of the clamps are making con-
tact with the terminals.
PRINTER DOOR OPEN
CLOSE DOOR AND TRY
TO PRINT AGAIN
√ Check that the door covering the printer paper is
properly closed and latched.
Troubleshooting the Display
If the display does not turn on:
• Checktheconnectiontothevehiclebattery.
• Thevehiclebatterymaybetoolow(below1volt)topowertheanalyzer.
Fully charge the battery and retest.
• The analyzer’s AA batteries may need to be replaced. (alkaline recom-
mended).
• IftheanalyzerdoesnotpoweronwhenyoupressandholdtheMENU but-
ton, replace the AA batteries.
