Midtronics Micro400XL User Manual

7
Return to service.
Fully charge the battery and return to ser-
vice.
Fully charge the battery and retest. Failure to
fully charge the battery before retesting
may cause false readings
Replace the battery and retest to perform
a complete charging system analysis.
A REPLACE BATTERY result may also mean
a poor connection between the vehicle’s
cables and the battery. After disconnecting
the vehicle’s battery cables from the battery,
retest the battery using the out-of-vehicle test
before replacing.)
Replace the battery and retest to perform a
complete system analysis.
Next, the analyzer will display for 3 seconds the percentage of state of
health as a bar graph.
The analyzer will then display for 3 seconds the percentage of state of
charge as a bar graph.
* When testing at Jump-Start Post, the analyzer may need to verify the
result. The analyzer will prompt you to retest at the battery posts.
* When testing at Side-Posts, the analyzer may detect corrosion
between the terminals and the side posts. The analyzer will prompt
you to check for corrosion and retest with adapters.
OPTIONS AFTER THE BATTERY TEST RESULTS
After the battery test results, press the INFO button for the option of
calculating the charge time required to fully charge the battery (available
only for batteries that produce a GOOD-RECHARGE or CHARGE &
RETEST result) or to retrieve a test code (if available). The INFO button
remains active during the results for the battery, starting and charging
systems tests.
Use the UP/DOWN ARROW buttons in the ADDITIONAL INFO screen
to select TIME-TO-CHARGE or TEST CODE and press ENTER.
Time-to-Charge
1. Charge Rate (Amps): Use the UP/DOWN ARROW buttons to select
the charge rate and press ENTER.
2. When the analyzer completes the calculation, it will display CHARGE
BATTERY with the time to charge in minutes at your selected
amperage rates.
3. Press ENTER to return to the battery test results.
GOOD BATTERY
GOOD-RECHARGE
CHARGE & RETEST
REPLACE BATTERY *
BAD CELL-REPLACE *
ENGLISH
GB
