Test Code (if available)
1. Select TEST CODE in the ADDITIONAL INFO screen; the analyzer
will display an encrypted 10-digit code.
2. Press ENTER to return to the test results or MENU for the menu
options screen.
STARTER SYSTEM TEST (Micro500XL)
NOTE: When testing older model diesel engines in cold
weather, preheating and post heating of the glow plug may
skew test results. Warm up the engine for 5 minutes before
the test.
If you selected the IN-VEHICLE battery test using the Micro500XL, the
display will toggle between the battery test result and the starter system
test screen. The Micro500XL will integrate the results of the battery test
with the starter diagnosis.
1. To begin the test, press ENTER.
2. The analyzer will prompt you to start the engine.
3. As the voltage rises, the analyzer will display one of the following
results:
CHARGE BATTERY: The starter voltage is low and battery is dis-
charged. Fully charge the battery and repeat the starter system test.
CRANKING VOLTAGE LOW (with voltage level): The starter voltage is
low and the battery is fully charged.
CRANKING VOLTAGE NORMAL (with voltage level): The starter
voltage is normal and the battery is fully charged
REPLACE BATTERY (if the battery test result is REPLACE or BAD
CELL): The battery must be replaced before testing the starter. Press
ENTER to perform the charging system test.
If the battery is good and fully charged and the vehicle will not start, see
“Starting Problems.”
Starting Problems
With the vehicle lights on:
If the engine does not crank and the lights dim heavily, check the
connections to ensure the wiring is clean and in good condition. If wiring
is in good condition, repair or replace the starter.
If the engine does not crank and the lights go out, there is probably a poor
connection. Check the connection to the battery and ground and ensure
they are clean and tight.
If the starter does not crank and the lights do not turn on, check for an
open circuit and retest the battery to ensure it is good and fully charged.
Replace any defective wiring and clean and tighten all wiring connec-
tions.
8
