Installation
90
Installing the steam oven
X
b
107
a
a
 Secure wood panels  with the 3 x 20 mm screws  supplied to the left hand
side of the niche.
Dimension x for niche height:
350 mm = 30 ± 5 mm
360 mm = 40 ± 5 mm
 Drill 2.0 mm Ø fixing holes in the wood trim.
 Push the appliance into position in the niche and align it.
Make sure that the mains connection cable does not get trapped or damaged
when doing so.
c
d
 Secure the appliance left and right using the wood screws supplied  (3.5mm
x 25mm) on the right and  (3 x 20mm) on the left.
Do not overtighten the screws as this will prevent the door from closing.
