Technical Information
24
DGC 6xxx
4 Service
4.1 Door Removal
1. Open the door wide.
2. Flip up the retaining brackets on each hinge; see Figure 020-1.
Figure 020-1: Hinge Brackets
3. Close the door to the point where resistance is felt when it is almost
closed.
4. Remove the door upwards; see Figure 020-2.
Figure 020-2: Door Removal
4.2 Door Disassembly
1. Remove the door; see Section 020-4.1.
2. Remove the two T20 screws securing the plastic corner bracket on each
side; see Figure 020-3, Item 1.
