Technical Information
86
DGC 6xxx
4.9 Inlet Valve Removal
1. Remove the appliance from its housing unit; see Section 010-4.1.
2. Disconnect the appliance from the power supply.
3. Remove the lid; see Section 010-4.2.
4. Disconnect the electrical connections from the inlet valves; see Figure
045-15, Item 1.
5. Remove the two T20 screws securing the inlet valve mounting bracket;
see Figure 045-15, Item 2.
6. Remove the inlet valves with mounting bracket from the appliance.
Figure 045-15: Inlet Valves
7. Turn the mounting bracket over and remove the four Phillips screws with
washers securing the inlet valves. See arrows, Figure 045-16.
8. Remove the inlet valves from the mounting bracket.
1
2
2
