Technical Information
96
DGC 6xxx
Operating mode Activated components Heater element
configuration
Convection broil Browning (R13) Figure 060-7
Broil element (R15)
Convection fan (M2-2)
Cooling fan (1M2-1)
Oven cavity lighting (1H3-2, 2H3-2)
Eco Broil Broil element (R15) Figure 060-8
Cooling fan (1M2-1)
Oven cavity lighting (1H3-2, 2H3-2)
Browning Browning (R13) Figure 060-6
Cooling fan (1M2-1)
Oven cavity lighting (1H3-2, 2H3-2)
Table 060-2: Operating-Mode Overview
1
Browning and broil elements are activated alternately.
3 Fault Repair
3.1 Fault Code F05 - Oven Pt1000 Temperature Sensor Short-
Circuited
Cause:
Oven Pt1000 temperature sensor (1R30-10) or its connections short-
circuited.
Remedy:
Install a new temperature sensor; see Section 035-4.2.
3.2 Fault Code F06 - Oven Pt1000 Temperature Sensor Open-
Circuited
Cause:
Plug at electronic module not connected or poor contact.
Remedy:
Check the plug for correct seating and contact.
If the sensor is defective, replace it; see Section 035-4.2.
Cause:
Oven Pt1000 temperature sensor (1R30-10) or its connections open-
circuited.
Remedy:
Check the temperature sensor. Replace if defective; see Section 035-4.2.
Cause:
Connection from oven temperature sensor to the power electronic open-
circuited.
Remedy:
Check the connection wire and replace it if necessary.
