Aligning the appliance doors
101
The appliance doors can be aligned
with the appliance housing after they
have been fitted.
In the following illustration, the
appliance door is not shown in the
closed position to make it easier to
see what you have to do.
To align the lower door use the long
outer slots in the lower hinge plate:
Remove the middle screw from the
hinge plate.
Slightly loosen both outer screws.
Align the door by sliding the hinge
plate to the left or right.
Then tighten screws again. The
screw does not need to be refitted.
