Changing the door hinging
97
Secure the door opening aid using
the screw with the plastic collar
and the screw without a plastic
collar. Do not overtighten the
screws!
Tip: Check whether the door opening
aid moves easily by pressing it. If it
does not move freely, the screws
should be loosened slightly.
Fit covers and.
Change the soft-close mechanism
over
If you want to limit the door opening
angle toapprox. 90° you need to fit
the door opening angle limiter
supplied before refitting the soft-close
mechanism (see “Door opening angle
limiter”).
Undo and remove screw on soft-
close mechanism and insert a
screwdriver behind the soft-close
mechanism.
Remove soft-close mechanism
and turn it through 180°.
