Changing the door hinging
99
Use your fingers to insert pin into
the door bearing bush.
Screw in pin (by approx. ¼turn)
until it clicks into position.
Fit safety cover on to the pin.
The appliance door is not secure until
safety cover has been correctly
fitted.
Secure the soft-close
mechanism
Open the door 90°.
Push on cover until it clicks into
position.
Push hinged arm into the opening
on the door hinge.
Insert pin into the door hinge from
above. Turn this with a screwdriver
(by approx. ¼ turn) until both lugs on
the pin click into position correctly in
the grooves.
Pull out red safety aid.
Tip: Keep the red safety aid in case you
want to change over the door hinging
again at a later date.
