Control panel for the freezer
a Access sensor
b Sensor for selecting the temperature
in the freezer
(X for colder; Y for warmer)
c On/Off sensor for the Super freeze
function
Control panel for the ice/water
dispenser
a On/Off sensor for the lighting
b Chilled water sensor
c Ice cube sensor
d On/Off sensor for the
ice/water dispenser
e Sensor for switching off the
temperature or door alarm
(only visible when the alarm is
sounding)
f Reminder to change the water filter
d Sensor for crushed ice
e On/Off sensor for the system lock
Description of the appliance
5
