Anti-tipping mechanism
The anti-tipping mechanism a supplied
is used to secure the building-in niche
b, to the wall, preventing the appliance
from tipping forwards.
,Danger of tipping.
The building-in niche must be
securely fixed to the wall behind
using a number of screws to avoid
the appliance tipping when it is
fixed into the niche later.
Use two anti-tipping mechanisms for
each appliance or four for each side-
by-side pair of appliances.
^
Place the anti-tipping mechanisms a
on the left- and right-hand sides of
the building-in niche, leaving
<10 mm distance to the side walls.
^
Mark the drilling position onto the
niche back walls and top panel
through the holes in the anti-tipping
mechanisms.
^ Put the anti-tipping mechanisms in a
safe place - they will be required
later.
Fixing screws for different uses and
types of material are supplied in the
accompanying pack.
If these are not suitable for the anti-
tipping mechanism in your
installation, you will need to secure it
by alternative means.
^
Secure the building-in niche to the
wall.
Installation
73
