Securing the ice/water
dispenser frame
The word "TOP" is marked on the rear
of the frame at the top.
With 19 mm thick furniture fronts:
^ Fit the frame onto the ice/water
dispenser and press it firmly into
position so that it sits evenly with the
furniture front.
With 38 mm thick furniture fronts:
^
Fit the secondary trim to the frame.
^
Fit the frame onto the ice/water
dispenser and press it firmly into
position so that it sits evenly with the
furniture front.
Installation
87
