Miele Freezer - Appliance Door Dimensions (Opening Angle 115°)

Appliance door dimensions (opening angle 115°)
AB CD
F 1472 Vi 525 mm Door front (max. 38 mm)* Door handle* 234 mm
* The dimensions for the door fronts and handles will vary according to the
individual kitchen.
Miele recommends using the full door opening angle of 115° for this freezer.
Installation advice
66
