Technical Information
105
G 5xxx
13. Disconnect the hoses.
14. Disconnect the NTC sensor connections.
15. Remove the drain pump. See Section 050-4.17.
16. Remove the circulation pump. See Section 050-4.13.
17. Remove the heater wiring harness from the cable guide on the sump.
18. Unscrew the hose clamp and remove it from the sump seal.
19. Remove the sump by pulling down firmly and evenly on the drain pump or
circulation pump connections.
20. Remove the sealing ring.
Note:
When installing, the following should be noted:
1. Install the sealing ring on the metal flange on the cabinet.
2. Apply liquid detergent as a lubricant to the outer surface of the seal.
3. Apply liquid detergent as a lubricant to the inside of the sump.
4. Before reusing the dishwasher, detergent residues must be flushed out
of the cabinet as otherwise these could cause a fault indication (see
Fault Code F52, Section 080-3.28).
5. Make sure that the arrows on the sump and cabinet base are aligned.
6. Align the sump with the connection to the drain. Install the cover and
filter combination.
7. Locate the clip lock in the middle between the two stoppers.
8. Tighten the hose clip on the sump.
Warning! To prevent possible leakages later on, do not overtighten the clip
on the sump.
4.23 Filter Combination Disassembly
Note:
During reassembly, a locking piece must be installed to prevent the filter
combination from falling apart; see Section 050-4.25.
As an alternative, the microfine filter and the handle piece (crown coarse
filter) must be replaced together; see Section 050-4.24.
1. Disconnect the appliance from the power supply.
2. Open the filter cap.
3. Place a screwdriver on the retaining clip spring and press against it; see
Figure 050-21.
4. Turn the handle clockwise and release the filter combination clip
connection.
