Technical Information
18
G 5xxx
2 Door Springs
2.1 Summary
Springs are always installed in pairs of the same tensile strength.
Color Tensile strength (lbs (N)) Length (in. (mm))
Orange Approx. 52 (230) 5.90 (150)
Uncolored Approx. 72 (320) 6.14 (156)
Green Approx. 92 (410) 6.10 (155)
Table C-6: Door Springs Summary
2.2 Standard Door Springs by Appliance Model
Model Width Spring color
Max. front panel
weight [lbs (kg)]
G 45x0 18” Orange 15.4 (7)
G 42x0 24" Uncolored 20.9 (9.5)
G 42x5, G 5xx5 24” Green 28.6 (13)
G 5xx0 24” Uncolored
20.9 (9.5)
Table C-7: Standard Door Springs by Model
3 Electrical and Plumbing Connections
3.1 Electrical Information
The appliance is equipped with a 4-foot power cord and molded NEMA 515
plug for connection to a NEMA 5-15R receptacle (120VAC, 15-amp, 3-prong,
grounded outlet).
It is recommended that the power outlet for the appliance be installed on the
wall (within the cabinets), adjacent to under-counter space where the
appliance is installed.
Ensure that the cabinets contain no rough edges that could damage the
power cord or drain hose. If metal cabinets are used, ensure that a rubber
grommet is installed around the opening.
Always exercise caution when sliding the dishwasher in or out, to prevent
damaging the power cord and/or hoses.
3.2 Hard-Wired Electrical Connection
Connect L1 (black) to L on the terminal block, N (white) to N on the terminal
block, and GND to the ground connector.
Note:
Hardwiring the dishwasher should only be done if required by electrical code.
