Note to the installer:
Please leave this instruction book
with the consumer for the local
electrical inspector’s use.
The minimum distances given in
these Installation Instructions must
be observed in order to ensure safe
operation. Failure to do so increases
the risk of fire.
The cabinetry and venting hood
should be installed first to prevent
damage to the cooktop.
The cooktop can only be installed
as shown in the illustrations while
maintaining the required safety
distances shown. Do not install the
cooktop between two tall cabinets, this
is a fire hazard.
A minimum distance of 2" (50 mm)
from the cooktop to the rear wall and
a side wall must be maintained for
safety.
The countertop must be bonded
with heat resistant (212 °F/100 °C)
adhesive to prevent distortion and
dissolving.
The cooktop must not be installed
over a dishwasher, refrigerator or
freezer. Heat radiated by the cooktop
may damage them.
recommended
not recommended
not allowed
IMPORTANT SAFETY INSTRUCTIONS
32
