Installation notes
63
All dimensions are given in mm.
Onset installation
Seal between the hob and the work-
top
Using sealant under the hob could
result in damage to the hob and the
worktop if the hob ever needs to be
removed for servicing. Do not use
sealant between the hob and the
worktop.
The sealing strip under the edge of
the top part of the hob provides a
sufficient seal for the worktop.
Tiled worktops
Grout lines and the hatched area un-
derneath the hob frame must be
smooth and even. If they are not the
hob will not sit flush with the worktop
and the sealing strip underneath the
hob will not provide a good seal
between the hob and the worktop.
