Installation
82
Flush-fit installation
Prepare the worktop cut-out Remem-
ber to maintain the minimum safety
distances (see "Safety distances").
Solid wood, tiled and glass worktops:
Fix a wooden frame5,5 mm below
the top edge of the worktop (see dia-
gram in "Building-in dimensions -
flush-fit hobs).
Attach the seal provided underneath
the edge of the hob.
Feed the mains connection cable
down through the cut-out.
Centre the hob in the cut-out.
The gap between the ceramic surface
and the worktop must be at least
2mm wide. This is so that the hob can
be sealed.
Connect the hob to the mains.
Check that the hob works.
Seal the gap between the hob and
the worktop with a silicone sealant
that is heat-resistant to at least
160°C.
Unsuitable sealant can damage nat-
ural stone.
For natural stone worktops and nat-
ural stone tiles, only use silicone
sealant that is specially formulated
for natural stone. Please follow the
manufacturer's instructions.
