Optional modules
46
Liquid dispensing (optional for machines with
dispensing drawer)
A
Dispenser pump
B
Siphon
a
Hose connection (suction side)
b
Hose connection (pressure side)
c
Leakage outlet
d
Suction inlet opening
e
Level sensor for level indicator. When the dispenser container is
empty, the pump and the machine switch themselves off.
Continuing the programme after a "Dispensing system
fault" message
When the dispenser container is empty, the pump and the machine
switch themselves off and the washing machine indicates a lack of
liquid detergent.
