Installation
*INSTALLATION*
59
Installation surface
A concrete floor is the most suitable
installation surface. It is far less prone
to vibration during the spin cycle than
wooden floorboards or a carpeted
surface.
The machine must be level and
securely positioned.
To avoid vibrations during spinning,
the machine should not be installed
on soft floor coverings.
If installing on a wooden joist floor:
Install the machine on a plywood
base (at least 70x60x3cm). The
base should span several joists and
be bolted to the joists and not only to
the floorboards.
Useful tip: If possible, install the
machine in a corner of the room. This is
usually the most stable part of the floor.
Removing the transit bars
Remove the left and right covers.
1. Pull off the transit bar covers and
2. and use a screwdriver to release the
catches at the top and bottom.
Using the spanner supplied, turn the
left-hand transit bar 90°.
