en - Installation
183
Unscrew the screws at the bottom of the back panel and remove
the panel.
Loosen the hexagon screws to remove the transport safety devices.
Retain the transport safety devices. They need to be refitted should
the machine ever need to be moved again.
Plumbing
Water pressure (flow pressure) of a minimum 1bar (100kPa) / max-
imum 10bar (1000kPa) is required to guarantee problem free pro-
gramme operation.
The machine must be connected to the water supply using the inlet
hoses provided.
Hoses must be replaced with hoses tested for a burst pressure of at
least 70bar (7000kPa) and for water temperatures of a minimum of
90°C.
This also applies for associated connection fittings. Miele original re-
placement parts fulfil these requirements.
Tip: The hot water supply must not exceed a maximum temperature
of 60°C.
