Miele PWM 514 - PWM 520 Machine Data; Electrical Connection; Installation Dimensions; Weight and Floor Load

en - Technical data
187
PWM520 machine data
Electrical connection
Supply voltage See data plate
Frequency See data plate
Power rating See data plate
Current consumption See data plate
Fuse rating See data plate
Heater rating See data plate
Installation dimensions
Casing width (without add-on components) 920mm
Casing height (without add-on components) 1450mm
Casing depth (without add-on components) 857mm
Overall machine width 924mm
Overall machine height 1452mm
Overall machine depth 950mm
Minimum width of transport opening 930mm
Minimum safety distance between wall and appliance front 1250mm
Weight and floor load
Net weight see installation plan
Max. floor load in operation see installation plan
Emissions data
Sound pressure level emission in workplace in accordance with EN ISO 11204/11203 <70 dB(A) re 20 μPa
Sound power level EN ISO 9614-2 <80 dB(A)
Product safety
Product safety standard
IEC 60335-1, IEC 60335-2-7
EN 60335-1, EN 50571
WiFi
Frequency range of the WiFi module 2.400–2.4835GHz
Maximum transmission power of the WiFi module <100mW
