Fitting a decor panel
The door has a decor frame for fitting a
decor panel (available as an optional
accessory).
Decor panel dimensions
Width. . . . . . . . . . . . . . 590 mm (-1 mm)
Height . . . . . . . . . . . . . 590 mm (-1 mm)
Thickness . . . . . . . . . . . . . . . . 0.6-4 mm
^
Open the door.
^
Unscrew the 4 screws on the upper
decor strip (see illustration).
^
Then take the upper decor strip off
by pulling it forwards.
^
Loosen but do not unscrew
completely, the screws on the three
remaining decor strips.
^
Move the decor strips forwards.
A decor panel up to 4 mm thick can
now be inserted.
^ Slide the decor panel in from above.
^ Press the decor strips into position
and tighten up the loosened screws.
^ Now push on the upper decor strip
from the front and secure this with
the 4 screws.
Installation
40
