Miele WWD320 WCS User Manual

Technical data
72
Height 850mm
Width 596mm
Depth 643mm
Depth with door open 1077mm
Height for building under 850mm
Width for building under 600mm
Weight Approx. 90kg
Capacity 8.0kg dry laundry
Supply voltage See data plate
Rated load See data plate
Fuse rating See data plate
Consumption data See “Consumption data”
Minimum water flow pressure 100kPa (1bar)
Maximum water flow pressure 1000kPa (10bar)
Water inlet hose length 1.60m
Drain hose length 1.50m
Connection cable length 2.00m
Maximum delivery head 1.00m
Maximum drainage length 5.00m
LEDs Class1
Test certifications awarded See data plate
Power rating in off mode 0,40W

Miele WWD320 WCS Specifications

General

Capacity	8 kg
Energy Efficiency Class	A+++
Spin Speed	1400 rpm
Noise Level (Spin)	74 dB
Dimensions (HxWxD)	850 x 596 x 636 mm
Color	White
Type	Front-loading
Noise Level (Wash)	50 dB
