TECHNICAL SPECIFICATIONS:
• Power supply: 8-26 Vac/dc.
• Current consumption: 1.5 mA typical.
• Relay rating: Latching relay.
Nominal switching capacity (resistive load) 1 Amp 30 Vdc, 0.5 Amp 125 Vac
Max. switching power (resistive load) 30 Watt, 62.5 V A
Max. switching voltage 110 Vdc, 125 Vac
Max. switching current 1 Amp
• Relay Trip Time: 2 seconds.
• Operating Temperature: -25°F (-14°C) to 125°F (69°C).
• Dimensions: 1-3/4” (44.5 mm) diameter x 16.5” (42 cm) long.
• Adjustable range: 3 -12 feet typical installation.
• Very low power consumption, ideal for battery application.
Troubleshooting: Make sure all connections are correct.
If the SENSOR is not working:
1. Make sure the Range Adjustment is set at maximum range.
2. Disconnect the power (battery) to the SENSOR.
3. Reconnect the power to the SENSOR and make sure that no metal object or vehicle is moving
around the SENSOR for 60 seconds while it is calibrating.
4. Test the SENSOR to verify that it is working properly.
5. Check that push/pull DIP switches on Control Board are set correctly.
