Mikado LOGO 800 - 1 Chassis; Chassis Assembly: Frame Connections

1
2
Bag 1
Use the included 2.5 mm
threaded rod to position
the 2.5 mm hex lock nuts
in the right hand side
frame.
Be sure to instert
the adapters
at this stage.
Manual LOGO 800 - ©Mikado Model Helicopters GmbH - Page 4
1 Chassis
M2,5 Stop
M2,5x6
M2,5x10
M2,5x12
M2,5x10
8x M2,5 Stop
4x M2,5x6
8x
M2,5x10
5x
1x
M2,5x12
2,5x60
12x M2,5
14x25x62x
