5. Installation
1
6 17
Bracket Pole Mounting
Solar Panel Installation
www.milesight.com
www.milesight.com
Bracket Wall Mounting
Drill 4 holes on the wall according to the mounting bracket and insert the wall plugs into
these holes. Then fix the mounting bracket to the wall by fixing the wall mounting screws
into the wall plugs.
Straighten the hose clamps and slide them through the rectangular rings in the mounting
bracket. Wrap the hose clamps around the pole, then use a screwdriver to tighten the
locking mechanism by turning it clockwise.
1. Fix the solar panel to the solar panel bracket using 6 fixing screws.
