PrestoCHILL
MM138-003 Operator Manual
12
2. INSTALLATION
Milestone PrestoCHILL is an instrument which requires the utmost care when it is unpacked and installed.
Provide a bench of at least 70cm (28in) in width and 70cm (28in) in depth and that can stand the
PrestoCHILL weight of 25kg (56lb).
At least 2 people should remove the unit from its box and locate it on the bench.
Then place PrestoCHILL on the bench, make sure that the unit is level and the bench is made of non-
flammable material and is vibration free. Ensure that the instrument has been positioned away from hot,
direct sunlight and is in a location completely free from drafts.
Make sure the unit is not placed against any side surface limiting the air cooling inlet/exhaust: allow
at least a distance of 20cm (7.9in) for each side and of 30cm (11.8in) behind.
2.1. Space Requirements
PrestoCHILL is delivered in a wood box with these dimensions:
Width: 420mm (17in)
Height: 680mm (27in)
Depth: 650mm (26in)
Unit dimensions:
Width: 300mm (12in)
Height: 450mm (18in)
Depth: 540mm (22in)
Space dimensions required to locate the unit:
Width: 700mm (28in)
Height: 800mm (31.5in)
Depth: 700mm (28in)
