MM138-003 – Operator Manual
38
6. PrestoCHILL OPTIONAL
Not included, to be ordered apart:
We advise against the use of optional other than those provided by Milestone.
6.1. Standard mould with different measures
MLD3228 2926-5
rectangular shape
chuck of 26 x 31mm
depth 5mm, weight 0.062kg
max sample size 26,5 x 23,5mm
REF 100590
MLD3228 2926-7
rectangular shape
chuck of 26 x 31mm
depth 7mm, weight 0.059kg
max sample size 26 x 23mm
REF 100694
MLD3030 2525-5
square shape
chuck of 28 x 28mm
depth 5mm, weight 0.063kg
max sample size 22.5 x 22.5mm
REF 100693
MLD3030 2525-7
square shape
chuck of 28 x 28mm
depth 7mm , weight 0.060kg
max sample size 22 x 22mm
REF 100698
MLD3030 2525-10
square shape
chuck of 28 x 28mm
depth 10mm , weight 0.056kg
max sample size 21 x 21mm
REF 100699
MLD3939 3333-5
square shape
chuck of 37 x 37mm
depth 5mm, weight 0.054kg
max sample size 31,5 x 31,5mm
REF 100692
MLD3939 3333-7
square shape
chuck of 37 x 37mm
depth 7mm, weight 0.048kg
max sample size 31 x 31mm
REF 100696
MLD3939 3333-10
square shape
chuck of 37 x 37mm
depth 10mm, weight 0.040kg
max sample size 30 x 30mm
REF 100697
