Miller Syncrowave 351 - Electrical Service Guide

OM-354 Page 16
3-9. Electrical Service Guide
All values calculated at 60% duty cycle.
NOTE
60 Hertz Models
Without Power
Factor Correction
With Power
Factor Correction
Input Voltage
200 230 460 575 200 230 460 575
Input Amperes At Rated Output
130 112 57 46 112 84 45 34
Max Recommended Standard Fuse Or Circuit
Breaker Rating In Amperes
200 175 80 70 150 125 70 50
Min Input Conductor Size In AWG/Kcmil
2 3 8 8 4 4 8 10
Max Recommended Input Conductor Length In
Feet (Meters)
150
(46)
168
(51)
262
(80)
409
(25)
117
(36)
154
(47)
273
(83)
287
(87)
Min Grounding Conductor Size In AWG/Kcmil
6 6 8 8 6 6 8 10
Reference: 1996 National Electrical Code (NEC) S-0092-J
All values calculated at 60% duty cycle.
NOTE
50 Hertz Models
Without Power
Factor Correction
With Power
Factor Correction
Input Voltage
220 380 415 220 380 415
Input Amperes At Rated Output
138 80 73 88 51 47
Max Recommended Standard Fuse Or Circuit
Breaker Rating In Amperes
200 125 110 150 80 70
Min Input Conductor Size In AWG/Kcmil
3 6 8 4 8 8
Max Recommended Input Conductor Length In
Feet (Meters)
125
(38)
214
(65)
170
(52)
141
(43)
187
(57)
222
(68)
Min Grounding Conductor Size In AWG/Kcmil
6 6 8 6 8 8
Reference: 1996 National Electrical Code (NEC) S-0092-J
