OM-236297 Page 30
Description
Part
No.
Item
No.
10-1. Consumables Flowchart (Continued)
Quantity
Table 10-5. Value Multi−Turn Contact Tips*
2 ♦071825 .030 in. (0.9 mm) 1... ......... .. ...................................................
2 ♦054202 .035 in. (0.9 mm) 1... ......... .. ...................................................
2 ♦054201 .045 in. (1.2 mm) 1... ......... .. ...................................................
2 ♦199593 .3/64 in. (1.2 mm) Aluminum Wire 1... ......... .. .....................................
2 ♦044006 .052 in. (1.3 mm) 1... ......... .. ...................................................
2 ♦047566 1/16 in. (1.6 mm) 1... ......... .. ...................................................
2 ♦202933 1/16 in. (1.6 mm) Aluminum Wire 1... ......... .. .....................................
Table 10-6. Gas Diffusers
3 ♦198857 1/8 in. Tip Recess − For Extra Heavy Duty FasTip Contact Tips 1... ......... .. ...........
3 ♦199623 Flush Tip − For Extra Heavy Duty FasTip Contact Tips 1... ......... .. ...................
3 ♦199621 1/8 in. Tip Recess − For Value Multi−turn Contact Tips 1... ......... .. ...................
3 ♦199622 Flush Tip − For Value Multi−Turn Contact Tips 1... ......... .. ..........................
3 227749 1/8 in. Tip Recess − For Heavy Duty FasTip Contact Tips... .......... ..
(Standard On All Guns) 1..............................................
3 ♦231511 1/4 in. Tip Recess − For Heavy Duty FasTip Contact Tips 1... ......... .. ................
3 ♦231512 Flush Tip − For Heavy Duty FasTip Contact Tips 1... ......... .. ........................
3 ♦209031 Slip On Recessed Diffuser (Requires Nozzle 209033 or 209034... ......... ..
and insulator 209047, Used With Any Tapered FasTip Contact Tip) 1........
3 ♦209032 Slip On Flush Diffuser (Requires Nozzle 209033 or 209034... ......... ..
and Insulator 209047, Used With Any Tapered FasTip Contact Tip) 1........
3 ♦209099 Spot Diffuser (Requires Spot Nozzle 176238 or176240 or 176242) 1... ......... .. ........
Table 10-7. Insulators
4 232284 Insulator, Nozzle Collared Diffuser 1... .......... .. .....................................
4 198856 Insulator, Rubber 1... .......... .. ...................................................
4 209047 Insulator, Teflon (Required When Using Diffuser 209031 Or 209032... .......... ..
With Nozzle 209033 Or 209034) 1......................................
Table 10-8. Barrel Assemblies
5 221087 Barrel Assy, Air Cooled Pistol 1... .......... .. .........................................
5 221519 Barrel Assy, Water Cooled Pistol 1... .......... .. ......................................
Table 10-9. Head Tube Assemblies
231523 Kit, Head Tube Assy Air Cooled Pistol 1................ .. .................................
231524 Kit, Head Tube Assy Water Cooled Pistol 1................ .. ..............................
♦OPTIONAL
*All contact tips are packaged in bags of 25.
BE SURE TO PROVIDE MODEL WHEN ORDERING REPLACEMENT PARTS.
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model is required when ordering parts from your local distributor.
