OM-254 449 Page 33
1 263 950 Torch Handle Kit (1)
2 249 971 Torch Trigger
Microswitch (1)...............
3 249 961 Leads, 20 ft (1)
3 249 962 Leads, 50 ft (1)
4 256 039 Torch Body Kit (1)
5 249 972 Torch Trigger Assembly
w/Spring (1)
252 951 Grease, Silicone (1)
249 953 Torch, Replacement 20 ft (1)
249 954 Torch, Replacement 50 ft (1)
See Figure 7-11 for
additional consumable parts.
1
1
2
3
4
5
Item
No.
Part
No. Description
Ref. 256 001-A
Figure 7-10. Torch, XT60
265 172-A
. For extended tip use, set Amperage control to 40.
Figure 7-11. Consumable Parts For XT60
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model is required when ordering parts from your local distributor.
