Milnor MWF63C Series Maintenance Guide

Pellerin Milnor Corporation 17
Table 2 Filters, Screens, and Sensitive Components (cont'd.)
Mark
Do this each
Component More Data. See also Section 3.1.2 , page 18
1 2 3 4
5 6
x
200 hours strainer for steam inlet.
(Steam is optional on
some models.)
See Figure 14, page 29
x
200 hours speed sensor photoeye.
Optional on some models.
See Figure 18, page 32
x
2400 hours proximity switches See Figure 19, page 32
3.1.1.3 Components that Become Worn
BNUUUH01.R12 0000399389 A.5 A.26 A.23 11/16/21 11:00 AM Released
Examine these items. Tighten or replace the item if necessary, to prevent shutdowns and un-
satisfactory performance. Speak to your dealer for replacement parts.
Table 3. Components that Become Worn
Mark
Do this each
Component
More Data
1 2 3 4
5 6
x
200 hours drive belts and pulleys See Section 3.2.1 , page 24
x
200 hours tubes and hoses (non-
hydraulic)
Examine hoses and hose connections for leaks.
x
200 hours tilt air bags See Figure 17, page 31
x
1200 hours door bumpers Replace if damaged.
x
200 hours rubber springs See Figure 23, page 36
x
200 hours shock absorbers See Section 3.3.3 , page 35
3.1.1.4 Bearings and Bushings
BNUUUH01.R13 0000399388 A.5 A.26 11/16/21 11:04 AM Released
Unless the item is sealed, apply grease to prevent damage. See the next section for motors.
Table 4. Bearings and Bushings
Mark
Do this each
Component More Data . See also Section 3.1.3 , page 19
1 2 3 4
5 6
Grease plate 01 10025Z for bearing housing. Use this data if your machine has this grease plate. See Figure 20, page 34
and Section 3.1.5 : Procedures for Bearing Components Connected to a Grease Plate, page 21. It is necessary to remove a
side panel on some models, to access this grease plate.
x
200 hours seal Add 0.06 oz. (1.8 mL) of grease EPLF2 (Table 8, page
20)
x
200 hours rear bearing Add 0.12 oz. (3.6 mL) of grease EPLF2
x
200 hours front bearing Add 0.12 oz. (3.6 mL) of grease EPLF2
Other Grease Ports
x
200 hours door hinge Figure 21, page 34. Add 0.12 oz (3.6 mL) of grease
EPLF2 (Table 8, page 20).
x
200 hours door latch plunger Figure 21, page 34. Apply stick DE3 (Table 8, page 20)
to surface.
x
200 hours door open plunger Figure 21, page 34. Apply stick DE3 (Table 8, page 20)
to surface.
x
600 hours motor and pump bearings See Section 3.1.6 : Procedures for Motors, page 21
Routine Maintenance
