MIMAKI UCJV150-160 User Manual

Chapter 5 Settings
113
5.2 Maintenance Menu
This menu is used for maintenance actions. It also lets the user perform nozzle recovery if nozzle clogging
persists even after cleaning and nozzle washing.
l
Maintenance Menu Screen
MAINTENANCE
STATION
>
>
NOZZLERECOVERY
>
AUTOMAINTENANCE
>
INKFILLING
>
INKTANKEXCHANGE
>><<
width:1340mm
REMOTEMENU
TEST PRINT
CLEANING
LOCAL
MAINTENANCE
OVERFLOWMAINTENANCE
>
AIRPURGE
>
>><<
MENU
SETUP
>
>
MAINTENANCE
>
MACHINESETUP
NOZZLECHECK
>
>
INFORMATION
>><<
l
Pressing the [TEST PRINT/CLEANING] key
TESTPRINT
>
>
CLEANING
>
STATIONMAINTENANCE
width:1340mm
REMOTEMENU
TEST PRINT
CLEANING
LOCAL
Maintenance Menu List
Item
Setting
*1
Details
Station - This moves the carriage to allow station and print head maintenance.
Carriage Out -
Station - Cleans around the station, including the cap, wiper, and NCU.
"Wiper Cleaning"(P. 132)
"Cap Cleaning"(P. 134)
"NCU Cleaning"(P. 135)
Head Maint. - Cleans around the print head.
"Carriage Underside Cleaning"(P. 136)
"Media Sensor Cleaning"(P. 141)
"Cleaning the Mist Filter"(P. 138)
"Mist Filter Replacement"(P. 149)
Nozzle Wash - Washes the print head nozzle surface with washing liquid to resolve
print defects (e.g., nozzle clogging, deflection).
"Print Head Nozzle Washing"(P. 139)
Pump tube
cleaning
- Washes the suction pump tube (below the cap).
"Ink Discharge Channel Cleaning"(P. 141)
Custody Wash - Perform this step if the machine will not be used for extended
periods. The function washes nozzles and drainage channels to
maintain the machine in optimal condition.
"When Not in Use for Extended Periods"(P. 143)
Replace Wiper - Use this function when replacing the wiper. Replacing the wiper
resets the wiper usage counter.
"Wiper Replacement"(P. 146)
5
