Mindeo CR40-2D - Introduction to installation

2
Charging time
approximately 1 hours
Light source
650nm visible laser diode
white light
Image size
/
1280×800 pixels
Scanning angle
/
Horizontal：42°，vertical：26.5°
Scanning angle
±50°，±65°，±35°
(Skew、Pitch、Roll)
±70°，±72°，360°
(Skew、Pitch、Roll)
Scanning rate
100±10 times/second
/
Barcode contrast
minimum 20%
Decode
capability
UPC-A，UPC-E，EAN-13，
EAN-8，ISBN/ISSN，Code
39，Code 39 full ASCII，
Code 32 ， Trioptic Code
39，Interleaved 2 of 5，
Industrial 2 of 5，Matrix 2 of
5，Codabar(NW7)，Code
128 ， Code 93 ， Code
11(USD-8)，MSI/Plessey，
UK/Plessey ， UCC/EAN
128，China Post，China
Finance，GS1 DataBar
(formerly RSS)variants
1D: UPC-A，UPC-E，EAN-13，EAN-8，ISBN/ISSN，
Code 39，Code 39 full ASCII，Code 32，Trioptic
Code 39，Interleaved 2 of 5，Industrial 2 of 5，Matrix
2 of 5，Codabar(NW7)，Code 128，Code 93，Code
11(USD-8)，MSI/Plessey，UK/Plessey，UCC/EAN
128 ， China Post ， China Finance ， GS1
DataBar(formerly RSS)variants
2D: PDF417，MicroPDF417，QR code，DataMatrix，
Aztec Code
Scan engine
uE966
ME5800
Minimum
resolution
4mil
HD: 1D (Code 39): 3 mil, 2D (QR): 5 mil
SR: 1D (Code 39): 4 mil, 2D (PDF417): 6.7 mil
Decoding depth
Code type
Code type
High
Density
Series(HD)
Standard
Range
Series (SR)
4mil (9B): 50-90mm
3mil Code 39（3B）
60–90mm
/
5mil (12B): 50-115mm
4mil Code 128（9B）
45–135mm
85–145mm
10mil (3B): 20-260mm
10mil Code 39（3B）
20–260mm
30–310mm
15mil (3B): 30-380mm
13mil UPC（6B）
17–275mm
25–330mm
20mil (3B): 45-490mm
20mil Code 39（1B）
38–410mm
30–485mm
30mi l(2B): 40-700mm
5mil QR（40 B）
55–95mm
/
55mil (2B): 80-850mm
6.7mil PDF417（20 B）
35–175mm
75–190mm
10mil QR（20B）
20–195mm
48–190mm
10mil DM（20B）
25–185mm
50–185mm
20mil QR（20B）
20–320mm
20–390mm
