Prefix transmission: By setting Enable, prefix will be appended before the data transmitted.
Suffix transmission: By setting Enable, suffix will be appended before the data transmitted.
Code name transmission: By setting Enable, code name will be transmitted before code data.
Preamble transmission: By setting Enable, preamble will be appended before the data transmission
Postamble transmission: By setting Enable, Postamble will be appended after the data transmission.
Code ID transmission: By setting Enable, Code ID can be transmitted in the format of either
Proprietary ID or AIM ID. Refer to 1-3 Default setting for each barcode.
Code length transmission: The length of code data string can be transmitted before the code data
transmitted when Enable is selected. The length is represented by a number with two digits.
Case conversion: The characters within code data or the whole output string can be set in either upper
case or lower case.
FN1 substitution transmission: The embedded scanner supports a FN1 substitution feature. The
replacement string of FN1 can be chosen by user (see 3-44 G1-G6 & C1-C2 & FN1 substitution string
setting).
All-non-printable-character string transmission with string setting: By setting Enable, all string settings,
e.g. Preamble transmission or Insert G1 string setting, are active for an all-non-printable-character
string. Here a non-printable character means a character with ASCII value between 0x00 to 0x1F.
Transmit the first N data characters only: The embedded scanner supports to only transmit the first N
data characters of a barcode. The number of N can be set as a digit between 1 and 99.
Transmit the last N data characters only: The embedded scanner supports to only transmit the last N
data characters of a barcode. The number of N can be set as a digit between 1 and 99.
