106
Example 2: Query current scan mode
1) Look up the parameter table in 6 Parameter Menus and the ASCII table in 11 ASCII table. The
target parameter index is “0401”.
2) The numeral system is decimal, thus, ‘D’ is used.
3) The value field is filled with ‘?’.
4) Put all above parts and then append a storage indicator ‘.’ to construct the command:
“<SYN>M<CR>0401?.”.
5) Upon receiving command, embedded scanner response with “0401D01<ACK>”.
Host: <SYN>M<CR>0401?.
