Mindray Accutor 7 - Removing the 5 G Wi-Fi Module (Optional, Only Available for Accutorr 7)6-15

6-15
6.4.3 Removing the 5G Wi-Fi Module (Optional, Only Available for
Accutorr 7)
1. Remove the antennas on the front panel from the slots as shown below:
2. Remove the antennas from the Wi-Fi module PCBA.
Antenna
Antenna
