Mindray Accutor 7 - Removing the Touchscreen; Disassembling the Display

6-18
6.4.6 Removing the Touchscreen
Unscrew the seven PT3×8 screws as indicated below. Remove the touchscreen assembly
and then the touchscreen.
6.4.7 Disassembling the Display
Unscrew the four M3×6 screws indicated below to remove the screen.
SD card
Touchscreen
