Mindray Accutor 7 - Exergen Temporalscanner Thermometer Assembly; Exploded View

7-14
Item
No.
Description FRU part number
9 Screw, Flat Head Phillips, M3X6 M04-005005---
10 Predictive Temperature module PCBA 051-001435-00
/ Predictive Temperature board cable 009-003368-00
/
Cable between the Temp
erature module and power
management board
009-003239-00
/
Cable between the isolation power board and
Temp
erature board
009-003240-00
7.11 Exergen TemporalScanner Thermometer Assembly
7.11.1 Exploded View
