BeneVision N22/N19/N17/N15/N12
Quick Reference Guide
c. Select the Setup tab.
d. Enable ST Analysis.
e. Select the Main Menu
quick key or to return to the main display.
Initiate QT Analysis
To enable the QT monitoring on the N Series bedside monitor:
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the QT tab
.
c. Select the Setup tab.
d. Enable QT Analysis.
e. Select the Main Menu
quick key or to return to the main display.
Selecting Leads for QT Calculation
To select one lead or all leads for QT calculation:
a. Select the QT numerics area, ECG numeric area, or ECG waveform area to
enter the ECG dialog.
b. Select the QT tab.
c. Select the Setup tab.
d. Set QT Leads.
e. Select the Main Menu
quick key or to return to the main display.
Initiate and Print a 12-lead ECG Report
To perform a Resting 12-lead ECG Analysis on the N Series bedside monitor:
a. Select the ECG Full-Screen
quick key.
b. Select Setup to enter patient information or adjust Report options.
c. Select Analyze.
d. Select Print to print out the 12-lead ECG report.
Or
a. Select the ECG numeric area or waveform area to enter the ECG dialog.
b. Select the Setup tab.
c. Verify Lead Set to 12-Lead.
To Next Page
