Mindray BeneVision N17 - BIS Expand View (Bilateral Sensor Required); Adjust Parameters; Alarms; Setting Parameter Alarm Properties

17
BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
To adjust the display in the BIS waveform area to include EEG, BIS Trends, or
Superimposed BIS Trends on the N Series bedside monitor:
a. Select BIS waveform or numeric tile on the main screen to enter the BIS
dialog.
Or
a. Select BIS from Parameters Setup dialog (
quick key).
b. Select Setup tab.
c. Select Display.
d. Scroll and select option.
e. Select the Main Menu
quick key or to return to the main display.
BIS Expand View (Bilateral Sensor Required)
To expand the BIS view on the N Series bedside monitor:
a. Select BIS waveform or numeric tile on the main screen to enter the BIS
dialog.
b. Select BIS Expand.
Adjust Parameters
To adjust the parameters displayed in the BIS numeric tile on the N Series bedside
monitor:
a. Select BIS waveform or numeric tile on the main screen to enter the BIS
dialog.
Or
a. Select BIS from Parameters Setup dialog (
quick key).
b. Select Select Parameter tab.
c. Select tile and select desired parameter from adjacent list.
d. Select the Main Menu
quick key or to return to the main display.
ALARMS
Setting Parameter Alarm Properties
The Alarm dialog allows the clinician to configure alarm properties on the N
Series bedside monitor.
