BeneVision TD60 Quick Reference Guide
SpO2 (OPTIONAL)
The TD60 allows continuous pulse oximetry.
Connect the SpO2 Module
Connect the SpO2 module to the TD60 as shown in the following figure.
Connecting the Masimo SpO2 module
SpO2 module
SpO2 sensor connector
SpO2 sensor
