8-22
SN Description FRU part number
8 new-knob-8 043-002226-01
10 Encoder board 0010-30-43089
11 Encoder cable 9200-21-10460
13 Screw, self-tapping, PT3×8 /
16 Cable between the touchscreen control board and the main board 009-001981-00
17 Signal cable for 8" screen 009-001983-00
18 Cable between the main board and backlight board (8") 009-001986-00
19 Bracket for 8" screen /
20 Touchscreen control board PCBA 051-000881-00
21 Screw, Pan Head Cross Recessed M3×6 /
22 Cable between main board and keypad board 009-001982-00
23 cPM 8 main board service kit 115-023212-00
24 Inner hexagon screw, M3×6 /
25 Cable between mother board and alarm lamp 009-001980-00
26 LCD, for cPM8 801-9261-00042-00
28 Touchscreen, resistive-type, 8.4" 4-line 021-000058-00/021-000271-00
29 Keypad board PCBA, 8.4 inch 051-000887-00
30 Power button 049-000366-00
31 8" button (English) 049-000364-01
8.4.3 Rear Housing Assembly
For the exploded view and parts list of the multi-parameter assembly, refer to section 8.2.3 Rear Housing Assembly.
8.4.4 Multi-parameter Assembly
For the exploded view and parts list of the multi-parameter assembly, refer to section 8.2.4 Multi-parameter
Assembly.
8.4.5 Battery Compartment Assembly
For the exploded view and parts list of the multi-parameter assembly, refer to section 8.2.5 Battery Compartment
Assembly.
8.4.6 NIBP Pump and Valve Kit
For the exploded view and parts list of the multi-parameter assembly, refer to section 8.2.6 NIBP Pump and Valve Kit.
8.4.7 IBP_C.O. Module Assembly
For the exploded view and parts list of the multi-parameter assembly, refer to section 8.2.7 IBP_C.O. Module
Assembly.
