Page #31 background imageLoading...
Page #31 background image
Parts Listing Parts
3 - 10 0070-10-0604-01 Duo Service Manual
3.2 Parts Listing
REF. NUMBER PART NUMBER DESCRIPTION
1 0211-00-0146 Housing Screw (metric panhead)
2 0380-00-0475 Rear Housing
3 0441-00-0107 Chassis
4 0671-00-0045 Power Supply Board
5 0211-00-0145 Metric Panhead Screw
6 0671-00-0044 CPU/Display Board
7 0213-00-0032 Self Tapping Screw
8 0380-00-0472 Nellcor Connector Shroud
8A 0380-00-0473 Masimo Connector Shroud
9 0380-00-0476 Front Housing
10 0012-00-1595 SpO
2
Power Cable
11 0671-00-0246 Masimo Isolated Power Board
12 0211-00-0143 Screw
13 0671-00-0243 Masimo SpO
2
Board
14 0012-00-1474 Masimo Flex Cable
15 0671-00-0247 Nellcor Isolated Power Board
16 0671-00-0242 Nellcor SpO
2
Board
16a 0671-00-0066 Nell-3 SpO
2
Board
17 0012-00-1457 Nellcor Flex Cable
17a 0012-00-1661 Nellcor Flex Cable
18 0386-00-0308 SpO
2
Mounting Plate
19 0104-00-0037 NIBP Module
20 0671-00-0063 Fan Driver Board
21 0671-00-0043 Battery Connector Board
22 0380-00-0481 Battery Latch
23 0380-00-0474 Battery Door
24 0346-00-0052 Battery Door Tether
25 0012-00-1592 Fan with cable
26 0348-00-0216 Fan Gasket
27 0213-00-4014 Screw
28 0386-00-0310 Fan Mounting Plate
29 0380-00-0471 Filler Panel
30 0367-00-0084 Handle
31 0211-00-0147 Handle Screw (metric panhead)
32 0334-00-1603-03 Rear Label, Lower, S/N
33 0348-00-0202 Foot
34 0380-00-0480-01 Power Switch Plunger
35 0380-00-0480-02 Clear Switch Plunger
36 0380-00-0480-03 Patient Size Switch Plunger
37 0380-00-0480-04 Start NIBP Switch Plunger
N/S - Not Shown
