Mindray Eagus R9 User Manual

9-48 Structure and Assembly/Disassembly
c) Insert the board into the system. See the figure below.
d) Push the clips of the TR64 board to tighten the TR64 board.
 Incorrect demonstration of TR64 board:
1
2
3
Do not touch the clip
inside the red rectangle.
Do not touch the clip
inside the red rectangle.
