Panorama® Service Manual 0070-10-0634 7 - 3
Appendix A Panorama Motherboard CMOS Setup/Verification
BIOS FEATURES SETUP
VIRUS WARNING: DISABLED
CPU INTERNAL CACHE ENABLED
EXTERNAL CACHE: ENABLED
QUICK POWER ON SELF TEST: ENABLED
BOOT SEQUENCE: CD-ROM, C, A
SWAP FLOPPY DRIVE: DISABLED
BOOT UO FLOPPY SEEK: DISABLED
BOOT UP NUMLOCK STATUS: ON
BOOT UP SYSTEM SPEED: HIGH
GATE A20 OPTIONS: FAST
TYPEMATIC RATE SETTING: DISABLED
TYPEMATIC RATE (CHARS/SEC): 6
TYPEMATIC DELAY (MSEC): 250
SECURITY OPTIONS: SETUP
PCI/VGA PALETTES SNOOP: DISABLED
MPS VERSION CONTROL FOR OS: 1.4
OS SELECT FOR DRAM > 64 MB: NON-OS2
VIDEO BIOS SHADOW: ENABLED
C8000-CBFFF SHADOW: DISABLED
CC000-CFFFF SHADOW: DISABLED
D0000-D3FFF SHADOW: DISABLED
D4000-D7FFF SHADOW: DISABLED
D8000-DBFFF SHADOW: DISABLED
DC000-DFFFF SHADOW: DISABLED
MPC ENABLE: DISABLED
MPC POST BOOT: DISABLED
MPB BAUD RATE: 57.6
CHIPSET FEATURES SETUP
AUTO CONFIGURATION: ENABLED
DRAM SPEED SELECTION: 60ns
MA WAIT STATE: SLOW
EDO RAS# TO CAS# DELAY: 3
FAST RAS# TO PRECHARGE TIME: 3
EDO DRAM READ BURST: x333
EDO DRAM WRITE BURST: x222
DRAM DATA INTEGRITY MODE: ECC
